XL6036B

1.Our proprietary designs and exacting manufacturing specifications insure that every machine we sell meets or exceeds our customers' needs and expectations.

2. The foundation of our commitment to deliver top-quality machines to our customers is our 100% inspection Quality Control process using state-of-the-art optical measurement systems to support both manufacturing and product design.

3. We believe that this is the only way to ensure that we deliver the finest products to customers who demand precise, reliable machines in their applications.

Model	XL6036B
Table size	1250x360 mm
Table travel(x/y/z)	900/320/400 mm
Table load capacity	400 kg
Spindle taper	7:24 ISO50
Distance from horizontal spindle to table	0-400 mm
Distance from horizontal spindle to arm	175 mm
Spindle speed range	60-1800(12 steps)
Range of longitudinal, cross travel	15-370(8 steps)(max.540)
Vertical up-down(z axis) speed table	590
T-slot NO./width/distance of rotary table	3/18/80
Cantilever travel	500 mm
Main motor	4 kw
Motor for rapid device of table	0.75 kw
Motor of lifted of table	1.1 kw
Motor of cooling of pumps	90 w
Speed of cooling of pumps	25 w
N.W/G.W.	2100/2400 kg
Overall dimension	2220x1790x1700 mm
